Voltage: AC100V-240V, 50/60Hz.

Power: 550W

Light source: 380W yodn bulb

Beam angle: 3.8 ° -45 °, zoom lens, linear zoom

Control channel: 16/22 standard DMX channels.

Control mode: voice control, self-propelled, master-slave, DMX512

Spot, beam, and wash 3in1 function.

Color wheel: 13 colors + white, linear color conversion and rainbow effect.

2 gobo wheels:

fixed gobo wheel: 14gobos + white color

rotating gobo wheel: 9 gobos + white light.

Prism: two independent prism discs, one 8 prism, one 3D effect 6 prism, (8, 16, 24 prisms can be selected), prism and prism front and back free rotation function, prism positioning function.

Focusing: DMX linear high-definition focusing, 2 meters to infinity sharpness adjustment, the far and near definition of the gobo can be adjusted freely.

Atomization: It can produce soft effect adjustment, 0%~100% linear atomization.

Strobe: Double-chip high-speed strobe, 1-15 times / sec.

Dimming: 0-100% mechanical linear dimming.

Horizontal/Vertical: Horizontal scanning angle 540°, vertical scanning angle 270°, 8 or 16Bit precision fine adjustment, automatic return and correction function; fast speed, smooth running without flick, low noise, accurate positioning.

Display: LCD liquid crystal display, can switch between Chinese and English display.

Lamp housing: high temperature engineering plastics and alloy materials, streamlined design, beautiful appearance.

IP level: IP20.

The console can be lit and the bulb can be switched on and off.

Dimensions: L450 × W410 × H670mm

Package size: L380×W300×H590mm

N.W.: 19KGS

G.W.: 22KGS
